Supports customization with a processing capacity of up to 15900 CFM (cubic feet per minute).
High Stability:Key heat exchangers are manufactured in-house. Refrigeration compressors are mainly sourced from well-known brands such as Panasonic, Copeland, Danfoss, and Hanbell, together with high-quality refrigeration components.
High-Efficiency Moisture Separation:Equipped with an independently designed and continuously upgraded water separation system, ensuring reliable and efficient moisture removal.
Wide Operating Range:Hydrophilic aluminum foil is used, while heat exchangers and pre-coolers are standard across the entire series, ensuring reliable operation even under demanding conditions.
Intelligent Dual-Compressor Design:Models from 5 to 180 m³/min feature a 1+1 dual-compressor configuration. The second compressor automatically starts or stops according to system load, improving energy efficiency and adapting to applications with significant fluctuations in air demand.
High Customization Capability:Custom colors and optional PLC control are available. Dry contacts, Modbus communication, IoT connectivity, and other functions can also be customized to meet specific customer requirements.
High-temperature compressed air containing moisture and oil first enters the water-cooled pre-cooler and air-to-air heat exchanger, where it is pre-cooled to reduce its temperature. It then passes through the air-to-refrigerant evaporator, where the compressed air is cooled to a dew point of 2–10°C.
During cooling, moisture, oil, and some impurities condense and are separated from the compressed air by the gas-liquid separator. The condensate is then discharged through an automatic drain valve.
Finally, the dry compressed air passes through the air-to-air heat exchanger, where it is reheated to near ambient temperature, providing clean, dry compressed air for downstream use.
To ensure stable drying performance and long-term reliability, the 8830 CFM Water-Cooled Refrigerated Air Dryer should be used under the following recommended conditions:
For the best operating result, the dryer should be installed in a clean indoor environment with stable power supply, proper ventilation, and reliable cooling water conditions. Pre-filtration and after-filtration are recommended to improve compressed air quality and help protect both the dryer and downstream equipment.
| Parameter | Specification |
|---|---|
| Model | 8830 CFM Refrigerated Air Dryer (Water Cooled) |
| Air Flow Capacity | 8830 CFM |
| Cooling Method | Water Cooled |
| Pressure Dew Point | 2–10°C |
| Refrigerant | R407C / R134a |
| Max Operating Pressure | 10 bar |
| Power Supply | 380V / 3Ph / 50Hz |
| Water Connection Size | 2″ BSP |
| Air Inlet/Outlet | 6″ ANSI Flanged |
| Dimensions (L × W × H) | 3500 × 1850 × 2400 mm |
| Net Weight | 1500 kg |
This model combines high airflow capacity, stable dew point performance, efficient water-cooled operation, and durable industrial construction, making it suitable for demanding plant environments with continuous compressed air demand.
The 8830 CFM Water-Cooled Refrigerated Air Dryer is ideal for industries that require large-volume, dry, and reliable compressed air for continuous production and equipment protection.
Suitable for CNC machining, plasma cutting, welding, forging, and other heavy industrial applications where dry compressed air helps reduce corrosion, protect machinery, and improve process stability.
Provides stable and dry compressed air for production, packaging, and laboratory systems where moisture control is important for equipment performance and product quality.
Helps prevent humidity-related defects in textile processing, molding, and plastics manufacturing by maintaining consistent compressed air quality.
An excellent choice for plant-wide compressed air supply systems serving multiple workshops or production lines, especially where high airflow demand and continuous-duty operation are required.
Used for instruments, valves, process control systems, and explosion-proof air applications where stable dry air is essential for safe and efficient plant operation.
Supports hygienic and consistent compressed air use in processing, packaging, and handling applications where moisture control helps protect product quality and maintain operational reliability.
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
High Stability
Key heat exchangers are manufactured in-house. Refrigeration compressors are mainly sourced from well-known brands such as Panasonic, Copeland, Danfoss, and Hanbell, together with high-quality refrigeration components.
High-Efficiency Moisture Separation
Equipped with an independently designed and continuously upgraded water separation system, ensuring reliable and efficient moisture removal.
Wide Operating Range
Hydrophilic aluminum foil is used, while heat exchangers and pre-coolers are standard across the entire series, ensuring reliable operation even under demanding conditions.
Intelligent Dual-Compressor Design
Models from 5 to 180 m³/min feature a 1+1 dual-compressor configuration. The second compressor automatically starts or stops according to system load, improving energy efficiency and adapting to applications with significant fluctuations in air demand.
High Customization Capability
Custom colors and optional PLC control are available. Dry contacts, Modbus communication, IoT connectivity, and other functions can also be customized to meet specific customer requirements.
The compressed air first enters the pre-cooler for initial cooling, and then passes through the pre-cooling/reheating section of the high-performance 3-in-1 plate heat exchanger for further cooling. It subsequently enters the evaporator section, where it is rapidly cooled and the condensed moisture is separated.The treated low-temperature compressed air then returns to the pre-cooling/reheating heat exchanger, where it exchanges heat with the incoming hot compressed air. This reheats the dry compressed air before it is discharged from the dryer.The refrigeration system precisely adjusts the compressor speed according to changes in system load. The operating frequency is automatically regulated to match the actual air treatment demand, ensuring stable and energy-efficient operation.
Low energy consumption: the three-in-one plate heat exchanger is adopted, and the whole machine can save 20~30% of energy consumption;
Low pressure drop: the pressure loss of the whole machine is less than 0.015MPa, which is lower than the national standard;
Low dew point: under standard working conditions, the pressure dew point is as low as 2~10℃, and the electronic bypass valve is adopted, making the system more stable;
Environmentally friendly and durable: the whole series adopts environmentally friendly refrigerant R410a/R407C, which meets international environmental standards and has a maximum pressure of 1.6MPa;
Ultra-Low Pressure Drop:The pre-cooler features a newly designed annular tube configuration with approximately three times more tubes than conventional designs. The increased flow area significantly reduces air resistance, resulting in an overall pressure drop of less than 0.1 bar.
Low Dew Point:An optimized integrated 3-in-1 design, combined with a unique water separation system, ensures a consistently low and stable pressure dew point.
Intelligent Control:Equipped with a PLC and touchscreen as standard. The system automatically adjusts the compressor’s refrigeration capacity according to the evaporator load, ensuring optimal and energy-efficient operation. An RS-485 communication interface is also included as standard.
