Supports customization with a processing capacity of up to 17660 CFM (cubic feet per minute).
Flexible Communication:RS-485 standard, with optional IoT connectivity.
Energy-Saving Control:EBZ200-2 reduces energy consumption by over 10%.
Dew-Point Control (Optional):Load-based control saves over 30% energy.
High-Performance Desiccant:20% extra filling ensures stable, efficient adsorption.
Premium Core Components:High-pressure blower, pneumatic valves, and efficient cooler ensure reliable performance.
Optimized Airflow Design:304 stainless steel piping and optimized airflow reduce pressure drop.
Smart Touchscreen Control:7-inch MCGS touchscreen enables real-time operating monitoring.
The Zero-Purge Blower-Heated Regenerative Desiccant Air Dryer is developed on the basis of the low-purge blower-heated regenerative desiccant air dryer, with the addition of an intercooler.
During the heating stage, ambient air is drawn in by the blower and heated by the heater. The heated air then passes through the regeneration tower to heat the desiccant and desorb the adsorbed moisture.
During the cooling stage, the air circulates continuously through the intercooler and regeneration tower in a closed-loop circuit, cooling the regenerated desiccant bed without using any dry product air. As a result, no compressed air is consumed throughout the entire regeneration process, maximizing compressed-air utilization and improving overall system efficiency.
To ensure stable performance and efficient operation, the Blower & Zero Purge Adsorption Dryer should be used under the following recommended conditions:
For the best drying effect and longer adsorbent service life, the dryer should be installed with proper pre-filtration and operated under stable inlet conditions. This helps protect downstream equipment, maintain consistent air quality, and improve long-term system reliability.
| Model | Airflow Capacity (m³/min) | Air Connection Size | Installed Power (kW) | Overall Dimensions (L × W × H, mm) |
|---|---|---|---|---|
| HRB-ZW/A100 | 13.5 | DN65 | 12.1 | 1955 × 1040 × 2350 |
| HRB-ZW/A120 | 17.5 | DN65 | 16.7 | 2090 × 1102 × 2311 |
| HRB-ZW/A150 | 21.5 | DN65 | 19.5 | 2098 × 1102 × 2511 |
| HRB-ZW/A180 | 25.0 | DN80 | 19.5 | 2148 × 1197 × 2437 |
| HRB-ZW/A200 | 28.5 | DN80 | 22.8 | 2293 × 1250 × 2500 |
| HRB-ZW/A250 | 32.0 | DN80 | 27.8 | 2179 × 1302 × 2766 |
| HRB-ZW/A300 | 37.0 | DN100 | 36.5 | 2412 × 1560 × 2792 |
| HRB-ZW/A350 | 41.5 | DN100 | 36.5 | 2477 × 1500 × 2822 |
| HRB-ZW/A400 | 45.0 | DN100 | 36.5 | 2477 × 1500 × 2825 |
| HRB-ZW/A450 | 50.0 | DN100 | 36.5 | 2480 × 1500 × 2825 |
| HRB-ZW/A500 | 55.0 | DN125 | 57.5 | 3030 × 1940 × 2958 |
| HRB-ZW/A550 | 60.0 | DN125 | 57.5 | 3030 × 1940 × 3158 |
| HRB-ZW/A600 | 65.0 | DN125 | 57.5 | 3030 × 1940 × 3160 |
| HRB-ZW/A700 | 75.0 | DN125 | 57.5 | 3030 × 1940 × 2888 |
| HRB-ZW/A800 | 85.0 | DN125 | 63.5 | 3030 × 1970 × 3046 |
| HRB-ZW/A900 | 95.0 | DN150 | 77.5 | 3306 × 2189 × 3078 |
| HRB-ZW/A1000 | 110 | DN150 | 77.5 | 3356 × 2150 × 3078 |
| HRB-ZW/A1200 | 120 | DN150 | 77.5 | 3570 × 2319 × 3130 |
| HRB-ZW/A1400 | 145 | DN200 | 105.5 | 3668 × 2548 × 3330 |
| HRB-ZW/A1600 | 165 | DN200 | 143 | 3590 × 2800 × 3380 |
| HRB-ZW/A1800 | 185 | DN200 | 146.5 | 4356 × 2708 × 3436 |
| HRB-ZW/A2100 | 210 | DN200 | 230.5 | 4400 × 2800 × 3440 |
| HRB-ZW/A2600 | 260 | DN250 | 257.5 | 4800 × 3000 × 3450 |
Note：For air volumes above 260 m³/min or special specifications (materials, temperature, or pressure), please contact our company or authorized dealers. Data is for reference only and may change without prior notice.
The Blower & Zero Purge Adsorption Dryer is widely used in industrial applications that require continuous dry compressed air, low operating cost, and reliable long-term performance. Its zero purge design makes it especially suitable for systems where compressed air savings and energy efficiency are important.
Provides stable low-dew-point compressed air for production lines, pneumatic equipment, and centralized compressed air systems, helping improve equipment reliability and reduce moisture-related downtime.
Suitable for processes that require clean, dry air to protect sensitive components, improve production stability, and reduce the risk of moisture contamination.
Used in packaging, conveying, and automated production systems where dry compressed air is needed to support consistent process performance and protect product quality.
Supports instrumentation air, control systems, and process air applications in environments where reliable drying performance and continuous operation are essential.
Provides dry compressed air for production and packaging systems that require stable air quality and dependable long-duty operation.
With a wide flow range and zero compressed air consumption during regeneration, this dryer is particularly well suited for large-scale compressed air systems where energy savings and operational efficiency are key priorities.
– As an air treatment and gas purification manufacturer, we can meet all your compressed air quality and industrial gas needs. This includes various filtering equipment and customized air quality services.
– Our company is always ready to provide explanations. Just share your air quality requirements and we can develop the best system for you.
Need help navigating our compressed air dryer offer? We are always ready to put together the solution that best meets your needs.
The independently developed EBZ200-2 multi-core driver can save more than 10% of the comprehensive energy consumption compared with the fixed cycle mode;
The communication can meet the user's requirements such as RS-485 (standard), IoT connection, etc.
The optional dew point energy-saving control can extend the adsorption time and reduce the comprehensive energy consumption by more than 30% under load fluctuation conditions;
Customized high-performance adsorbent, 20% filling margin;
304 stainless steel control gas pipeline, specially designed diverter, high adsorbent utilization rate, small gas pressure loss;
7-inch Siemens touch screen programmable controller, dynamic monitoring of operation process；
The communication can meet the user's requirements such as RS-485 (standard), IoT connection, etc.
The independently developed EBZ200-2 multi-core driver can save more than 10% of the comprehensive energy consumption compared with the fixed cycle mode;
The optional dew point energy-saving control can extend the adsorption time and reduce the comprehensive energy consumption by more than 30% under load fluctuation conditions;
Customized high-performance adsorbent, 20% filling margin;
304 stainless steel control gas pipeline, specially designed diverter, high adsorbent utilization rate, small gas pressure loss;
7-inch Siemens touch screen programmable controller, dynamic monitoring of operation process；
