A refrigerated air dryer for air compressor is an essential component in any compressed air system that requires clean, dry air. This dryer removes moisture from compressed air using a cooling process, reducing the air temperature to condense and separate water vapor. The result is dry, high-quality air that protects downstream equipment and ensures optimal system performance.
The refrigerated air dryer for air compressor is designed for efficiency, low maintenance, and long-term reliability, making it ideal for a wide range of industrial and commercial applications.
Key Features of Refrigerated Air Dryer for Air Compressor
✅ Efficient Moisture Removal
The refrigerated air dryer for air compressor effectively reduces the dew point of compressed air to +2°C ~ +10°C, preventing moisture-related damage.✅ High-Performance Heat Exchanger
Advanced aluminum or stainless-steel plate heat exchanger ensures efficient heat transfer and stable operation.✅ Automatic Drain System
Removes condensed water automatically, preventing accumulation and minimizing manual intervention.✅ Compact and Space-Saving Design
The refrigerated air dryer for air compressor is designed with a small footprint, perfect for limited installation spaces.✅ Energy-Saving Refrigeration System
Uses eco-friendly refrigerants (R134a/R407C) with low energy consumption and high thermal efficiency.✅ Durable Build and Quality Components
Built with corrosion-resistant materials and globally recognized brand components for extended service life.
Operating Conditions & Technical Requirements
| Parameter | Specification |
|---|---|
| Working Pressure | 0.4 – 1.0 MPa (4 – 10 bar) |
| Inlet Air Temperature | ≤ 45°C (113°F) |
| Ambient Temperature | 5°C – 45°C (41°F – 113°F) |
| Pressure Dew Point | +2°C to +10°C |
| Cooling Type | Air Cooled or Water Cooled |
| Power Supply | AC 220V/1Ph/50Hz or 380V/3Ph/50Hz |
| Refrigerant Type | R134a / R407C |
These conditions are ideal for the refrigerated air dryer for air compressor to function at peak performance and provide reliable air drying results.
Technical Parameters (Sample Models)
| Model | Capacity (CFM) | Power (kW) | Connection Size | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|---|
| RD-50 | 50 | 0.5 | DN20 | 600×450×750 | 45 |
| RD-100 | 100 | 0.85 | DN25 | 700×500×850 | 65 |
| RD-200 | 200 | 1.2 | DN32 | 850×600×950 | 90 |
| RD-500 | 500 | 2.5 | DN50 | 1100×800×1250 | 180 |
| RD-1000 | 1000 | 4.5 | DN80 | 1400×900×1500 | 300 |
Custom configurations are available to match your refrigerated air dryer for air compressor application.
Application Scenarios
The refrigerated air dryer for air compressor is suitable for various industries and scenarios where dry compressed air is crucial:
🏭 Manufacturing Plants – Prevents equipment corrosion, clogging, and product contamination.
🎨 Painting & Coating Lines – Ensures moisture-free air for flawless surface finishes.
🧪 Laboratories & Medical – Provides clean air to meet hygiene and purity standards.
🚚 Automotive Workshops – Improves the performance of pneumatic tools and systems.
🏗️ Construction Sites – Keeps air tools operating at peak efficiency and durability.
Wherever compressed air is used, the refrigerated air dryer for air compressor ensures it’s dry and reliable.
Frequently Asked Questions (FAQ)
Q1: What is the function of a refrigerated air dryer for air compressor?
A: The refrigerated air dryer for air compressor reduces the dew point of compressed air by cooling it and removing condensed moisture, ensuring dry, clean air for downstream use.
Q2: What is the dew point achieved by this dryer?
A: The refrigerated air dryer for air compressor can achieve dew points between +2°C and +10°C under standard working conditions.
Q3: How is the dryer cooled?
A: It is available in both air cooled and water cooled models. Air cooled is suitable for most applications with good ventilation.
Q4: Does this dryer require maintenance?
A: Minimal maintenance is required. Regular checks on filters, condensate drains, and refrigerant levels ensure optimal performance.
Q5: Can I use this dryer with any air compressor?
A: Yes, the refrigerated air dryer for air compressor is compatible with most brands and models, provided the air flow and pressure ratings match.
Why Choose Our Refrigerated Air Dryer for Air Compressor?
🔩 Over 15 years of professional manufacturing experience
🌍 Exported to over 30 countries with excellent feedback
🔧 Customized solutions for diverse industrial requirements
🧊 Eco-friendly refrigerants with high cooling efficiency
📞 Free technical support and fast delivery
✅ Contact Us Today
Ensure your air system performs at its best with our high-efficiency refrigerated air dryer for air compressor. Reach out now to get a quote, download datasheets, or request customization.
